Thermacore® Sectional Steel Door - 596

Model 596

The Thermacore^® Sectional Door Model 596 is ideal for extra heavy-duty applications where both thermal efficiency and sound suppression are desirable. The 596 is constructed of 20-gauge galvanized steel with a flush, textured finish. The sectional steel door model 596 incorporates the Thermacore^® steel-polyurethane-steel panel construction, which provides a thermal barrier to withstand harsh climates and demanding environmental requirements.

Overview
Documents

Construction

Product Specifications
Standard Max Width	36’2″ (11,024 mm)
Standard Max Height	24’1″ (7,341 mm)
Panel thickness	2″ (51 mm)
U-factor*	.10
R-value**	17.4 (3.06 W/m2)
Sound Transmission Class 26	Ideal for applications that require sound control
Air infiltration	at 25 mph (40 kmp/h) .13 cfm/ft² (2.37 m³/hr/m²)
Thermal break	PVC
Exterior Steel	20-gauge galvanized
Exterior Surface	Flush, textured
Standard Springs	10,000 cycles

_{*U-factor values are independently tested and verified per ANSI/DASMA 105.}
_{**Overhead Door uses a calculated door section R-value for our insulated doors.}

Warranty

10 year limited delamination
1 year limited on door
3 year/20,000 cycle limited on door & operator system (when purchased together; on material and workmanship)

BIM

Thermacore Sectional Steel Doors Model 596 – BIM (opens in a new window)

Shop Drawing

Specifications

Product Literature

Instructional Manuals

Thermacore® Models 591, 592, 596, 599 Installation Instructions (opens in a new window)

Warranties

2465 N Miami Ave, Fresno, CA 93727, United States

Business Hours

Monday-Friday: 7:00 AM – 4:30 PM
Saturday-Sunday: Closed

CA Contractors License #474830

Come Visit Us

“Overhead Door is a trademark and the Red Ribbon logo is a registered trademark of Overhead Door Corporation”.

Terms & Conditions | Privacy Policy | Cookie Policy

Web Design and Digital Marketing by Lead Nurture Close Marketing

Benefits of Thermacore® Sectional Steel Doors

The Thermacore® Sectional Steel Door offers a range of benefits, making it an ideal choice for both residential and commercial applications. Its exceptional insulation properties enhance energy efficiency, helping to reduce heating and cooling costs while maintaining a comfortable environment.

Additionally, the door's robust construction ensures durability and longevity, which is crucial for high-traffic areas. With a high sound transmission class rating, it effectively minimizes noise, making it suitable for locations where sound control is a priority.

Thermacore® Sectional Steel Door Customization Options

Customers can customize the Thermacore® Sectional Steel Door to meet specific aesthetic and functional requirements. Options include various colors, finishes, and panel styles that allow homeowners and businesses to match their doors with existing architecture or branding.

Moreover, additional features such as windows, decorative hardware, and specialty insulation can be incorporated, ensuring that each door not only performs well but also enhances the overall appearance of the property.

Installation Process for Thermacore® Doors

The installation process for Thermacore® Sectional Steel Doors is designed to be efficient and straightforward. It is recommended to have a professional installer who is familiar with the product to ensure proper fitting and functionality.

During installation, the door is carefully measured and aligned to guarantee optimal performance and longevity. The included instructional manuals provide detailed guidance, ensuring that all safety and operational standards are met during the installation process.

Maintenance Tips for Thermacore® Sectional Steel Doors

To extend the lifespan of your Thermacore® Sectional Steel Door, regular maintenance is essential. Simple practices such as lubricating moving parts, checking seals for wear, and cleaning the door surface can prevent issues and ensure smooth operation.

Additionally, it's advisable to schedule professional inspections periodically. These inspections can identify potential problems early on, allowing for timely repairs and maintaining the door's efficiency and appearance over time.
